Core 1U
Specs
General information
Weight
20.2 kg (44.53 lbs)
Dimensions
434.0 mm (17.08 in) × 42.8 mm (1.685 in) × 751.48 mm (29.59 in, ear to rear wall)
Power supply
Dual redundant, 800W MM (100–240Vac), hot-plug
BTU rating
3000 max theoretical
Camera capacity
Up to 64 channels of 5MP cameras with full analytics capabilities
Camera compatibility
Any RTSP IP camera
Recording retention
30 / 60 / 90 days depending on customer selection
Remote viewing
Mobile or PC
Hardware
Form factor
Rack mounted 1U
CPU
AMD EPYC 9124, 3.0GHz, 16 cores / 32 threads, 64MBcache (200W) DDR5-4800 XL
GPU
NVIDIA L4, PCIe, 72W, 24GB Passive, Single Wide Low Profile
RAM
128GB total (8 × 16GB RDIMM)
Operating system
Linux
Storage
Chassis
3.5" with up to 4 × SAS3/
SATA drives (front-
accessible, hot-plug)
RAID controller
PERC 11
Raw storage options
32TB / 64TB / 88TB
enterprise-grade drives
Hardware RAID
Yes, with extensive configuration options
Dual OS drives
Yes, RAID1 SSDs
Network
Interface
Dual Port 1GbE(RJ45) +
1 × iDRAC/Mgmt
Remote management
iDRAC9 Enterprise 16G
Environmental
Operating temperature
10° - 35° C / 50° - 95° F
Storage temperature
-40° - 65° C / -40° - 149° F
Humidity
10-85% RH (non-condensing)
Server maintenance
IT software enablement
Yes
Resource allocation
Per VM
CPU
2 core
Memory
16 GB
Reliability and ownership
Redundancy
Full hardware: dual OS
drives, dual hot-plug power
supply, RAID storage
Credential and key encryption
TPM 2.0
Onsite hardware
repair/replacement
Next business day
Additional server applications
Bring-your-own IT software stack
Customer support
24/7 global support
Warranty
Leased: Lifetime
Purchased: 3 years,
extendable to 5 years
Regulatory model
E97S
Regulatory type
E97S001
